Integrally Forged Flanged Stainless Steel Bellows Globe Valves

Product Overview

Integrally Forged Flanged Stainless Steel Bellows Globe Valves

Applicable Standards:
Gate valve, API602
Steel Valves, ASME B16.34
Face to face ASME B16.10/MFG’S STANDARD
Socket Welded ASME B16.11
 Screw Threaded AEME B1.20.1/BS 21
End Flanges ASME B16.5
Butt welding ends ASME B36.10M
Inspection and test API 598

Material: Forged Steel (F316)
Size Range: 1/2"~2"
Pressure Rating: ASME CL, 150, 300, 600, 900, 1500, 2500
Temperature Range: -196°C~600°C
Design Description: Flange Ends

Product Description

Product features

1. Forged steel construction: These valves are made from high-quality forged steel materials, such as carbon steel, stainless steel, or alloy steel, to ensure durability and reliability in demanding applications.

2. Bellows seal design: The bellows seal provides a secondary stem seal that isolates the valve stem from the process fluid, preventing leakage and ensuring a tight shut-off.

3. Flanged end connections: The valves are equipped with flanged end connections that allow for easy installation and maintenance in piping systems.

4. Globe valve design: The globe valve design features a globe-shaped disc that moves perpendicular to the flow direction to regulate the flow of fluid and provide precise control.

5. Bolted bonnet or pressure seal bonnet: The valves may have a bolted bonnet or pressure seal bonnet design for easy maintenance and repair.

6. Rising stem and handwheel: The rising stem and handwheel provide visual indication of the valve position and allow for manual operation.
